The J1.5-3.5GX maintains a leading edge for the counterbalanced electric rider in today’s continuously evolving market.
Designed to manoeuvre in the tightest of spaces, to load and unload lorries in the most efficient manner, and to move pallets in containers and warehouses.
Through a redesigned drive axle, this battery electric unit now shares the same robust structure as its internal combustion equivalent.
AC motor technology on traction and integrated hoist/ steering allows the truck to work reliably over long runs and in demanding work cycles, reducing downtime significantly.
Offering excellent manoeuvrability for narrow aisle applications, a refined short chassis option is offered for the 2 tonne and 3.5 tonne models to facilitate all application requirements.
Through an integrated turning speed control system, truck lean is minimised to provide the operator with an enhanced feel of control and confidence in fast paced applications.
AC controlled traction and integrated hydraulic/steer motors provide optimised responsiveness to the operator, providing the most efficient load handling in the toughest of applications.
The option of horizontal battery extraction enables an easy exchange of batteries to drastically increase uptime.
Customisable performance settings allow energy efficiency to be ideally balanced with productivity, delivering high throughput at a lower operating cost.
Increased battery life up to 8.5 hours in standard performance mode, and 9.5 hours in Eco mode increases uptime and reduces electricity costs.
Fault code registry enables diagnostic ease. This enables cutting-edge maintenance planning for lowering costs and increasing productivity.
Model |
Load Capacity |
Load Center |
Lift Height |
Turning Radius |
Battery capacity |
J1.5GX |
1500kg |
500mm |
6025mm |
1845mm |
48V / 390-525Ah(V/Ah) |
J1.8GX |
1800kg |
500mm |
6025mm |
1875mm |
48V / 390-525Ah(V/Ah) |
J2.0GX |
2000kg |
500mm |
6035mm |
1990mm |
48V / 440-700Ah(V/Ah) |
J2.0GXS |
2000kg |
500mm |
6030mm |
1910mm |
48V / 390-525Ah(V/Ah) |
J2.5GX |
2500kg |
500mm |
6035mm |
2035mm |
48V / 565-700Ah(V/Ah) |
J3.0GX |
3000kg |
500mm |
6025mm |
2190mm |
48V / 440-600Ah(V/Ah) |
J3.5GXS |
3500kg |
500mm |
6030mm |
2255mm |
48V / 440-600Ah(V/Ah) |
